- SIGNA MR355 / SIGNA MR360
- Service Manual
- 5856356-3EN Revision 5.0
- Basic Service Documentation. Copyright General Electric Company.
- 00000018WIA30F81130GYZ
- id_152710554.0
- Feb 21, 2021 9:11:59 PM
1.5T Coil Vendor Manuals
| Table 5 |
| Table 6 |
| Table 7 | Table 8 | |
| Table 12 | ||
| Table 1 | Table 4 | |
| Table 2 | Table 9 | |
| Table 3 | ||
| Table 10 | ||
| Description | MCAT# | MFG | Service Docs | ||||
| HD 4CH Breast Array | M3335SB | Invivo | Service Manual | ||||
| 1.5T HD Vibrant Bilateral Breast Array Coil | M3087JG | GE | SNR | Installation | FRU | ||
| 1.5T Vanguard Breast MRI Tabletop Coil |
M3340CW | Sentinelle | Multiple. Refer to Service Manual | Multiple. Refer to Service Manual |
Service and Install Manual: PDF Operator Manual: PDF | 1.5T Vanguard Breast MRI Tabletop Coil FRU | |
| Description | MCAT# | MFG | Service Docs | ||||
| Signa HD 1.5T 8-CH Body Array Coil | M3335MC | USAI | SNR Test |
Coil Cable Replacement
Handle Replacement | FRU | Troubleshooting | Misc Items |
| HD 12 Ch Body Array | Single Connector: M3335LE | USAI | 1.5T 12-Channel Body Array Coil Setup for MCQA Test | 1.5T HDx 12-Channel Body Array - Single Connector Cable Replacement | 1.5T 12-Channel Body Array Coil FRUs | 1.5T 12-Channel Body Array Coil Troubleshooting | 1.5T 12-Channel Body Array Coil Introduction |
| Description | MCAT# | MFG | Service Docs | ||||
| HD T/R Quad Extremity coil | M3335ME | Invivo | SNR Test | FRU | Replacing 1.5T HD Quad Extremity Coil Pre-Amp | ||
| HD 8CH Wrist Array | M3335LJ | Invivo | SNR Test | Replacement | FRU | Troubleshooting | Misc Items |
| 1.5T HD T/R Knee Array | M3087JF | Invivo | SNR Test | Maintenance/Replacement | FRU | Installation/Troubleshooting | Misc Items |
| GE 8Ch Foot Ankle Coil | M50002GF | GE | 8 Channel Foot Ankle Coil Field Replacement Units | ||||
| Description | MCAT# | MFG | Service Methods | ||||
| 1.5T 4CH Small Flex Coil | M50002HP | GE | SNR Test | FRU | Installation/Troubleshooting | Misc Items | |
| 1.5T 4CH Large Flex Coil | M50002HN | GE | SNR Test | FRU | Installation/Troubleshooting | Misc Items | |
|
GEM Flex Coil 16-L Array, 1.5T Receive Only GEM Flex Coil 16-M Array, 1.5T Receive Only GEM Flex Coil 16-S Array, 1.5T Receive Only | M7000SH |
NEO | SNR Test | GEM Flex Coil Field Replacement Units | |||
| 16-Channel Flex Coil Foot/Ankle/Knee Positioner | M7005BE | GE | FRU: 5437192 | ||||
|
1.5T 8ch Flex 70 Array A port 1.5T 8ch Flex 50 Array A port 1.5T 8ch Flex 40 Array A port |
M7006PB M7006PC M7006PD | RFT | SNR test, replacement troubleshooting info please refer to DOC2013043 1.5T 8ch Flex Suite Service Manual | 1.5T 8 Channel Flex Coil Field Replacement Units | |||
| Description | MCAT# | MFG | Service Manual | ||||
| 1.5T Split Head Coil Assembly | GE | SNR Test | Replacement | FRU | Troubleshooting | Misc Items | |
| HD 8Ch HiRes Brain Array for HDe | M3335BN | Invivo | SNR Test | Replacement | FRU | Troubleshooting | Misc Items |
| Description | MCAT# | MFG | Service Manual | ||||
| 8ch Neurovascular Array | M3335M | Invivo | SNR Test Setup | Replacement | FRU | Troubleshooting | Misc Items |
| 1.5T HNS (Head, Neck, Spine) Coil |
M5000AT | GE | 1.5T Head Neck Spine (HNS) Coil MCQA Setup | 1.5T HNS Coil Cable Replacement 1.5T HNS Mirror Repair/Replacement 1.5T HNS NCU Connector Bracket Replacement | 1.5T Head Neck Spine (HNS) Coil Field Replacement Units | 1.5T HNS Coil Troubleshooting | 1.5T Head Neck Spine (HNS) Coil Introduction |
| Description | MCAT# | MFG | Service Docs | ||||
| Signa HD 1.5T 3CH Phased Array Shoulder Coil | M3335MN | USAI | SNR Test | Replacement | FRU | Troubleshooting | Misc Items |
| HD 1.5T 8Ch Reveive Only Shoulder Coil | M3340CE | NEO Coil | SNR Test | ||||
| Description | MCAT# | MFG | Service Docs | ||||
| 1.5T HD 8 Channel CTL Coil | M3335TC | GE | SNR Test | Replacement | FRU | Troubleshooting | Misc Items |
| Description | MCAT# | MFG | Service Manuals | ||||
| 3" Round Coil 1.5T | M1085GA | GE |
Note: For SIGNA Creator / Explorer, SIGNA MR355/ MR360, setup phantom and coil for SNR check without phantom positioner. Refer to Phantom Setup for 3 inch and 5 Inch Coil SNR Check for phantom setup procedure. |
FRU 2127315 : 3 Inch Coil | |||
| 5" Round Coil 1.5T | M1085HA | GE |
FRU 2127316 : 5 Inch Coil | ||||
| HD Dual Array Adapter | M3335MG | GE |
FRU 5140889 : HD Dual Array Adapter | ||||
| Surface Coil Adaptor Single Ch., 1.5T - HDx | GE |
FRU 5140888 : Single Ch Adapter | |||||
| Surface Coil Position Holder | M1087EE | GE |
FRU 46–258800G1 HEAD & POSITIONER | ||||
| Description | MCAT# | MFG | Service Docs | ||||
| Express Anterior Array, 4–element (for 8CH) | M50002BD | GE | SNR Test | Replacement | FRU | Troubleshooting | Misc Items |
| Posterior Array | GE | FRU | Troubleshooting | Misc Items | |||
| Express Head Neck Array, 14–element (for 8CH) | M50002BE | GE |
Express Coil: Head Neck Array Coil Cable Replacement Express Coil: Head Neck Array Coil ID PCB Replacement | FRU | Troubleshooting | Misc Items | |
| Express Head Neck Array, 16–element (for 16CH) | M50002HL | GE | MCQA |
Express Coil: Head Neck Array Coil Cable Replacement Express Coil: Head Neck Array Coil ID PCB Replacement | FRU | Troubleshooting | Misc Items |
| Express Anterior Array, 9–element (for 8CH) | M50002HM | GE | Replacement | FRU | Troubleshooting | Misc Items | |
| Description | Service Documents |
| ATD HD 8ch Body Array Assembly coil | No service information is currently available for this unit. Installation and configuration information is shipped with the ATD-T Assembly. This unit is compatible with the EXCITE Low Profile Carriage Assembly (LPCA).
|
| Description | MCAT # | Mfr | FRU | Service Documents |
| 1.5T Signa Cardiac Coil | M3335MD | USAI | Cardiac Coil Field Replacement Units | 1.5T Signa HD Cardiac Coil Introduction |
| 1.5T Signa HD Cardiac Coil Setup for Coil MCQA Test | ||||
| 1.5T Signa HD Cardiac Coil Cable Replacement | ||||
| 1.5T Signa HD Cardiac Coil Field Replaceable Units | ||||
| 1.5T Signa HD Cardiac Coil Troubleshooting |
