1.5T 4 CH Large Flex Coil Introduction

Overview

Follow this process to review the miscellaneous items for 1.5T 4CH Large Flex Coil by GE.

Miscellaneous Items

Product Identification and Shipping List

To identify the 1.5T 4CH large Flex Coil, refer to the coil label.

Figure 1. 1.5T 4CH large Flex Coil Label
Figure 2. 1.5T 4CH Flex Coil
Table 1. Shipping List
Description GE Part# Qty
1.5T 4CH Large Flex Coil Collector Kit54306931

Compatibility

The 1.5T 4CH Large Flex Coil is compatible with the GE 16 BEAT MR System.

Related Documentation

Operator’s Guide, GE Part Number 5430691-299 for 1.5T 4CH Large Flex Coil.

Environmental Requirements

Storage Requirements

Coil should be stored in the scanner room; the place required to store in scanner room is 100X470X720 mm
