Provides instructions for installing the respiratory connector or patient alert connector.
Prerequisites
| Personnel requirements |
|---|
| Required persons | Preliminary requirements | Procedure | Finalization |
|---|
| 1 | - | 10 minutes | - |
| Tools and test equipment |
|---|
| Item | Quantity | Part number | Manufacturer |
|---|
| Nonmagnetic Titanium Service Tool Kit, Small Set | 1 | 5113258 | - |
| Replacement parts |
|---|
| Item | Quantity | Part number | Manufacturer |
|---|
| Panel Coupling, Patient Alert Tube | 1 | 5335813-2 | - |
| Panel Coupling, Respiratory Tube | 1 | 46-265651P1 | - |
Procedure
- Replace and tighten the nut to secure the respiratory connector or patient alert connector.
Figure 1. Pneumatic connectors
| 1 | SB bracket |
| 2 | Patient alert connector |
| 3 | Respiratory connector |
- Connect the respiratory tube or patient alert tube.
