1.5T Head Neck Spine (HNS) Coil Introduction
Product Identification and Shipping List
HNS Rev 03 for Discovery MR450 and Optima MR450w Systems
Figure 1. HNS Rev 03 Coil Labels
Shipping Contents and Packaging List: 2-Connector Coil System
| Part Name | Part Number | Quantity |
|
2423192 | 1 |
| TL Spine Unit | 2423194 | 1 |
| Neck-Chest Unit | 2423193 | 1 |
| Patient Comfort Pad - Transition | 2417243 | 1 |
| Right Shoulder Pad | 2417244 | 1 |
| Left Shoulder Pad | 2417245 | 1 |
| Patient Comfort Pad - TL | 2417246 | 1 |
| Patient Comfort Pad - Head | 2417247 | 1 |
| Wedge Pad | 2417649 | 2 |
| Head Unit Cable - P Connector (Attached to Coil) | 2423972 | 1 |
| TL Cable (Attached to Coil) | 2423005 | 1 |
| Operator Manual | 2423588-500 | 1 |
| HNS Phantom Positioner | 5344844 | 1 |
Related Documentation
Operator’s Guide, GE P/N 2423588-500 for HNS Rev 03 coil.
Environmental Requirements
Storage Requirements: Coil should be stored in the scanner room.
