Front End Bell Replacement

Prerequisites

Table 2. Tools and test equipment
Item	Quantity	Effectivity	Part number	Manufacturer
12-inch length of 1/2-inch I.D. hose	1	-	-	-
2 hose clamps for 1-inch O.D. hose	1	-	-	-
4-inch-long piece of copper tubing, 1/2-inch O.D.	1	-	-	-
Roll of paper toweling	1	-	-	-
Pair of latex gloves	(optional)	-	-	-
Non-magnetic torpedo level or similar	1	-	-	-
Epoxy-filled Gradient Coil cart (2134810), cradle (2134810-2), and accessory kit (2134810-4).	1	-	2144093	-
Class 1 electric rider lift truck, 4-wheel, rated at 6000 lbs (in case the coil, cart, and cradle must all be lifted together— a necessity in mobiles); with forks a minimum of 56 inches long; with side shifter for easy width adjustment and lateral movement of forks.	1	-	n/a	-
Non-magnetic tool kit	1	-	46-320273G1, G2, G3, or G4	-

Table 3. Required conditions
Condition	Reference	Effectivity
Verify that the Epoxy-filled Gradient Coil accessory kit contains all the parts listed in Kit Contents.	-	-

No finalization steps.
