1.5T Head Neck Spine (HNS) Coil Introduction

Product Identification and Shipping List

HNS Rev 03 for Discovery MR450 and Optima MR450w Systems

Figure 1. HNS Rev 03 Coil Labels

Shipping Contents and Packaging List: 2-Connector Coil System

Table 1. Box 1 Content
Part Name Part Number Quantity

  • HNU Posterior Unit

  • HNU Anterior Unit

  • Anterior Adapter Unit

24231921
TL Spine Unit24231941
Neck-Chest Unit24231931
Patient Comfort Pad - Transition24172431
Right Shoulder Pad24172441
Left Shoulder Pad24172451
Patient Comfort Pad - TL24172461
Patient Comfort Pad - Head24172471
Wedge Pad24176492
Head Unit Cable - P Connector (Attached to Coil)24239721
TL Cable (Attached to Coil)24230051
Operator Manual 2423588-5001
HNS Phantom Positioner53448441

Related Documentation

Operator’s Guide, GE P/N 2423588-500 for HNS Rev 03 coil.

Environmental Requirements

Storage Requirements: Coil should be stored in the scanner room.
